CerCell ApS products

With a Vessel Volume (VV) of only 500 ml CerCell cover from as little as 100 ml Working Volume (WV). The 500 ml SUB is also available with classical signal pH SUS and DO Single-Use-Well and bio mass Single-Use-Sensor all pre-installed.

Most popular size of CerCell`s Single-Use-Bioreactor`s (SUB`s) for electrical blanket thermal control. Outside dimension (OD) 137 x 270 mm = 3,2 liter Vessel Volume (VV) in one-piece rigid USP class-6 PC. Available in many different standard models. Standard product which do not require specialized help from CerCell.

Single-Use-Fermenter (SUF) in this small size is unique. Standard product which require no involvement of specialized help from CerCell. Thermal control (most often cooling) by liquid when inserted into the Heating-Support-Foot (HSF). 500 ml Vessel Volume BactoVessel mounted in Heating Support-Foot (pn 2262W). HSF mounted in SUB-Support-Square (SSS) (pn 2259-137-15) on MST (pn 2250-C-8B). Latest BactoVessel with as much as 4 PG 13,5 ports. Unique opportunity for fast and small scale fermentation on larger PCS equipment as to the modular setup. Small Single-Use-Fermenter (SUF) with outside dimension OD 82 x 120 mm in one-piece PC vessel. Including 1 Rushton turbine, 4 x PG 13,5 ports. Available with Magnetic-Bottom-Drive (MBD) for drive on any +5 watt Magnetic-Stirrer-Table.

For perfusion systems not integrating a SUB CerCell offer the “HighRider” upstream solution for your own final assembly. Dip tube connection for alternating SUB broth through the HFF to the ATF-2 pump. The HighRider-2 is designed specifically to fit the ATF-2 / XCell-2 semi-ready perfusion system.

CellVessel series of configurable Single-Use-Bioreactors (SUB) are ideal for batch and fed-batch cultivation of various cell lines in suspension. CellVessel are unique as the SUB is fully configurable and meet all design request in a scalable platform ranging 1-25 litre Working-Volume (WV). Check out the many sizes under Commerce and see examples one step below this page. Contact us so we can help you configure, design the special SUB you want.
