Zgtek - Model R-6-300 Economic Series -Automatic Ring Making & Welding Machine
Features: R-6-300 E-Series is not equipped with digital regulation of ring sizes, max wire thickness it can work with is 5mm. High precision: intelligent "S" shape speed curve, the encoder and the motor form a closed-loop wire feeding control system, secure a diameter tolerance less than 0.16mm, eventually solve the ring precision issues inherent in the traditional mechanical or hydraulic ring making machines.
Most popular related searches
- High stability: wire feeding unit is driven by two motors directly without gears, belts or other transmission parts which would get less precise due to wear-out.
- Easy operation: ring size is adjusted by turning the wheels, much easier than traditional mechanical or hydraulic machines.
- Automatic ring welding: worker attendance is not required during machine operation.
- Compatible welding: capable of welding low, medium and high carbon steel, spring steel, galvanized steel.
- Model: R-6-300 E-Series
- Input voltage: 380V(3-phase) or custom
- Power frequency: 50/60Hz
- Instant power during welding: 15KVA(for 4mm wire)
- Instant power during forming: 2KVA
- Wire thickness: 2-5mm
- Max ring diameter: 300mm(can be customized to 600mm)
- Min ring diameter: 70mm(can be customized to 50mm)
- Ring perimeter tolerance: 0.5mm
- Cooling: Natural cooling
- Air flow required: 250L/min
- Air pressure: 0.6-0.8MPa
- Throughput: about 1560pcs/hr(for ring diameter 150mm)
- Weight: 1000KGS
