Model 10 Ton Per Hour -Automatic Sand Carbon Filter

Quartz sand carbon filters;
Quartz sand filter can filter to remove large particles of suspended solids in water, filter backwash regularly required to remove the retention of suspended solids, sand filter media tank filter with quartz sand in the main, to remove the water oxidation, rust, colloid, sediment, etc., the effluent becomes clear. Device automatically on a regular basis according to water washing. 10-20 minutes each wash. (This equipment mainly for processing of turbidity).

Quartz sand carbon filters;
Activated carbon filters are mainly used to remove organic matter, colloidal silicon, chlorine, etc., on the odor, color, very heavy metal ion adsorption capacity. Use shell activated carbon water treatment industry, to improve product taste. Water or carbon series of high quality coconut shell as raw material, advanced equipment, microcomputer control the production process conditions, refined processing. Products have developed pore structure, high strength, low impurity content. Stars Liaoduo appropriate, the resistance is small, easy regeneration and so on. For water purification with excellent results, it can not only remove the odor differences in water, improve water purity, various impurities in water such as chlorine, mercury, chromium, arsenic, lead, cyanide, pesticides, hazardous substances have to wait until the very high removal rate. Can be filled with different kinds and sizes with a wide range of water purifiers. Currently widely used pure water, mineral water production, as well as indoor and outdoor air purification. Control part of the automatic control, (economic) 10-20 minutes each wash. (Mainly the former sand filter treatment, the enhanced adsorption purification).

Automatic water softener:
Automatic water softener works: The hardness of water by one of the major cations: calcium (Ca2 +), magnesium (Mg2 +) ion composition. When the raw water containing hardness through the exchanger resin layer, the water calcium and magnesium ions adsorbed by the resin, while the release of sodium ions, so that the water flow within the exchanger is softened to remove hardness ions, calcium absorption when the resin and magnesium ions reach a certain saturation, the water hardness increases, then water softener will be automatically according to pre-program failure resins regeneration work, the use of higher concentrations of sodium chloride solution (salt water) through the resin, so that failure the resin restored to the sodium resin.

The main features of the automatic water softener:

1. A high degree of automation, water conditions stable, long service life. Full automatic, just regular salt, without human intervention.
2. high efficiency, low power, low operating costs. Reasonable because the overall design of water softener, the resin exchange capacity into full play, the energy consumption of the device itself was significantly lower than the general indicators of demineralized water devices, automatic control devices do not require full-time operator, which gave the user with to many facilities, and produce good economic benefits.
3. the device compact, small footprint, no special equipment base, placed on a flat concrete floor can be.
4. easy to use, installation, commissioning, operation is simple, stable performance control unit, the user can remove the worry.
5. anti-corrosion, anti-pollution, control valves, tank lining the exchange of non-toxic, PE plastic material of the salt boxes, which are sufficient to guarantee the equipment corrosion-resistant, anti-pollution, non-toxic, tasteless, harmless excellent performance .

Automatic water softener range of applications:
Industrial boilers, central air conditioning, heat exchangers, hotels, restaurants, food chemicals, laundry printing, medical and health needs to soften water to prevent fouling class produces a variety of industries.

Automatic water softener product structure:
Automatic water softener consists of three parts:

1. the original controller (including computer control and multi-valve system to the set);
2. made tank parts (including the exchange of tank and salt tank, fiberglass materials);
3. device accessories section (including the upper and lower water distributor, the center tube, Salt, salt pipe, sewage pipes, filters, etc.);

Automatic water softener specifications:

1. water pressure :0.25-0 .45 MPa, the best of 0.3MPa;
2. the water hardness: ≤ 6.5mmol / L (if the raw water hardness exceeds this target, need to re-design);
3. the water hardness: ≤ 0.03mmol / L;
4. the raw water temperature :2-50 ¡æ;
5. Power: AC22DV 50Hz, power 10-50W;
6. resin Model: 00lx7 strong acid cation resin;
7. body material: high-strength plastic
8. tank material: FRP winding tank
9. water consumption:

Automatic water softener is to run and regenerated softener every step to achieve automatic control, and the use of time, traffic or other sensors, etc. to start the regeneration. The basic composition of automatic water softener as: multiple control valve, resin tank (with 001 * 7 resin), salt boxes and piping systems.
