BSD - Model 660 Series -Automatic Specific Surface Area and Micropore Analyzer
The BSD-660 series is a cutting-edge, fully automated physisorption analyzer designed for precise surface area and porosity measurements using the volumetric method. Ideal for characterizing materials such as battery cathodes, porous substances, pharmaceutical compounds, and catalysts, the BSD-660 excels in analyzing MOFs, carbon materials, zeolites, LFPs, and various microporous (0.35nm-2nm) and mesoporous (2nm-50nm) materials. Built for high throughput, the BSD-660 enhances lab efficiency by automating tests, reducing manual labor, and improving accuracy. Its innovative A/B station design, with up to 12 in-situ analysis ports, allows independent operation with two gases and different test settings, offering unparalleled flexibility and boosting overall lab productivity.
- 3/6/9/12 analysis ports;
- Pore size 0.35nm-500nm;
- Specific surface area> 0.01m²/g ;
- Full automatic In-situ activation& analysis;
- Vaccum System: 10^-2 Pa with mechanical pump, 10^-8 Pa with molecular pump.
- Full Automation : In-situ degassing and testing without manual handlement
- High-Throughput : Up to 12 samples analyzed in one time;
- ≥ 0.001m2 /g : Surface Area
- 0.35nm- 500nm : Pore Size
- High Precision : RSD< 0.5% (Reference materials )
- Pressure Control Heating : PCH protect pore structure and prevent material being blown away
- Zero Helium Contamination : No removal of samples cell; heating degassing by molecular pump
- Multiple Gas Inlets : Multi-inlet for adsorbate gas analysis
- Self-diagnose : Intelligent equilibrium judgement and Test Monitoring
