SPEL Tankstor - Below Ground Tanks
SPEL Tankstor Below Ground Tanks are designed to meet diverse storage needs, offering a range of horizontal and vertical tank options with varying capacities. The horizontal tanks come in series from 200 to 600, providing capacities between 1,000L to 300,000L, while vertical tanks span capacities from 1,700L to 115,930L. These tanks are crafted in accordance with BS EN 13121 standards, ensuring quality and longevity, with a life expectancy of over 50 years. Comprehensive specifications cater to different invert levels and site conditions. The tanks feature standard pipe connections and are customizable to suit specific requirements. Access solutions include a variety of shafts and GRP ladder options, providing modular configurations. An option for double skin or secondary containment is available for enhanced safety, with integrated monitoring for leak detection. These tanks are ideal for various applications, including process buildings and remote locations.
SPEL Tankstor tanks are manufactured for many applications and in a wide range of specifications to handle such substances as water, sewage, farm effluent, petroleum products and chemicals.Our modern plant, equipment and quality assurance procedures ensure market-leading quality.Being manufactured in glass reinforced plastics, SPEL tanks are lightweight, easy to handle and install. They are not susceptible to rust, exhibit excellent corrosion resistant properties and have a life expectancy in excess of 50 years.For full SPEL Tankstor specification information, go to our SPEL Tankstor introduction page here.
Shell Design
Designed with reference to BS EN 13121. All tank shells carry the SPEL 25 Year Warranty and life expectancy in excess of 50 years.
Shell Specifications
Different tank shell specifications are available dependent upon tank invert levels, ground conditions and ground water levels. (See Installation Guidance section)
Inlet/Outlet Connections
Pipe connections available to accommodate most standard sizes.
For full SPEL Tankstor specification information, go to our SPEL Tankstor introduction page here.
Product Range
H Series | Horizontal Tanks
200 Series
(1.2m inside diameter):
1,000 – 10,000L capacity
300 Series
(1.8m inside diameter):
4,000 – 40,000L capacity
400 Series
(2.6m inside diameter):
13,650 – 100,000L capacity
500 Series
(3.5m inside diameter):
60,000 – 200,000L capacity
600 Series
(4.0m inside diameter):
100,000 – 300,000L capacity
V Series | Vertical Tanks
200 Series
(1.2m inside diameter):
1,700 – 5,000L capacity
300 Series
(1.8m inside diameter):
5,000 – 15000L capacity
400 Series
(2.6m inside diameter):
10,000 – 36,500L capacity
500 Series
(3.5m inside diameter):
50,400 – 90,100L capacity
600 Series
(4m inside diameter):
65,668 – 115,930L capacity
- Stormwater attenuation
- Fire fighting sprinkler reservoirs
- Potable water storage
- Septic/settlement tanks
- Cesspools
- Silage effluent holding tanks
- SPEL RainSave rainwater reservoirs
- Accidental spillage containment
- Transformer oil dump tanks
- Packaged pumping chambers
- Chemical spill tanks
