USI - Model 400 BT -Benchtop Coating System

FromUltrasonic Systems, Inc.

SHARE

The PRISM-400 BT Benchtop Coating System is an X-Y-Z motion and positioning platform designed for the application of a wide variety of coatings for R&D and lab-scale requirements. All PRISM systems leverage USI’s proprietary, nozzle-less ultra-Thin Coating Application Technology (tCAT) which delivers a more precise coating application than conventional spray nozzles, film coaters, roll coaters, and jetting technology.

Most popular related searches

positive displacement meter

positive displacement pump

liquid flow controller

liquid metering system

liquid flow control

Features and benefits:

Proprietary, nozzle-less ultra-Thin Coating Application Technology (tCAT)
Additional spray and dispense technologies available
Configurable, flexible platform to suit the requirements of precision coating applications in various markets, including:
Semiconductor Packaging
Display
Fuel Cell
Medical

Multiple liquid delivery system configurations including:
- Precision Metering Pump liquid delivery systems, features:
  - 50 ml capacity disposable syringe (PMP-50)
  - 100 ml capacity glass syringe (PMP-100)
  - Micro-stepping drive positive displacement liquid metering pump
  - Optional integrated liquid stirring to keep suspensions mixed
  - Data logging
- Pressurized reservoir with liquid solenoid valve for flow control
Internal mini-PC for Windows 10 based Graphical User Interface
Laser pointer for programming
3 axes (X-Y-Z) of motion with crash prevention sensor on Z-axis
Designed to spray flammable solvents
Isolated and ventilated spray area
Optional 590 ml reservoir with stirring
Optional substrate heater with vacuum
Optional spray head rotation and tilt function
Optional hotplates with various configurations
