- Truss depth: 24 in (.61 m)
- Basic machine length: 30 ft (9.1 m) – can be extended to 66 ft (20.4 m)
- Paving width: 63 ft (19.5 m) maximum – 12 ft minimum
- Heavy-duty legs: 4 in (0.10 m)
- Four machine travel bogies with 3 ft (0.9 m) wheelbase (two driver and two idler)
- Manual crown adjuster
- Crown may be changed at any hinge point or at any travel rail adjustor
- Operating weight: 4,550 lbs (2,064 kg)
- Dual 4 ft (1.2 m) long paving rollers
- Dual strike-off auger with double flighting
- Patented Rota-Vibe®
- Adjustable finishing pan with burlap drag or astro-grass drag
- Carriage pivoting cylinder
- Paving roller rotation kit
- Standard—Two 20 HP (15 kW) gas engines, one mounted on the frame at the operator`s station that drives the machine and carriage travel. The second is mounted on the carriage and drives the paving rollers and two augers.
- Optional—liquid-cooled diesel engines
- Automatic machine move-up at the end of each paving carriage pass 0-12 in (0.37 m)
- Automatic cushioned paving carriage travel reversal
- Operator can stop and reverse carriage travel at any point
- Extension inserts available in 15 ft (4.6 m), 12 ft (3.7 m), 6 ft (1.8 m), 4 ft (1.22 m), 3 ft (0.9 m) and 2 ft (.61 m) lengths
- Machine travel wheels: concave, flat-flanged or flat-flanged neoprene with removal flanges
- Skew bar kit (paves skewed decks with a crown)
- Hydraulic-powered paving roller lift kit
- Swing legs
- Travel dolly with towing tongue
- Paving carriage, low-pressure fogging system
- Pressure washer (portable or machine-mounted)
- Single internal vibration system
