Envea - Model CO12e e-Series -Carbon Oxides Analyzer
FromENVEA
Non Dispersive Infra Red Carbon Monoxide Analyzer for CO measurements in the range 0-50ppm. CO2 monitoring as option. The CO12e analyzer is an Eco-designed, reference air quality monitor, QAL1 certified by the TÜV, US-EPA approved and compliant with ISO 4224. It offers superior metrological performances for CO measurements in the range 0-300 ppm. CO2 measurement optionally (range: 0-2000 ppm by NDIR).
More about this product— External link
Most popular related searches
infrared carbon monoxide analyzer
2008/50/EC
air quality monitoring
NDIR hydrocarbons
industrial fence line monitoring
ambient air quality monitoring
fence line monitoring
carbon oxides analyzer
gas filter correlation
continuous emissions monitoring system
- Cost-saving Carbon Monoxide monitor with ultra low power consumption offering compliance with EN 14626 (2012), EN 15267, 2008/50/EC, ISO 4224, 40 CFR PART 53 SUB B & SUB C
- Excellent sensitivity & signal stability, great accuracy and repeatability
- Real-time calibration graph, animated synoptic, auto-diagnostic, control and maintenance data screens can be displayed while the instrument is operating
- Service assistance inside: detects early signs of trouble, allows predictive maintenance, identifies the needed service and guides service operations step by step: increased productivity on site, reduced downtime, more efficiency, less training…
- Includes Communication Protocol for XR® Software with automatic recognition and configuration
- Automatic recognition of plugged electronic boards or optional devices: plug & play principle
- Smart, connected instrument with embedded web server for the easiest, full remote control and operation of the analyzer from any PC, tablet or smartphone (configuration, calibration, test, diagnostic parameters…)
- Integrated web-server with full remote emulation of the analyzer through the ENVEA Connect free app
- Additional parameter: CO2
- Built-in module for CO2 monitoring (range: 0-2000 ppm by NDIR)
- RS232 or RS485 Serial interface (via USB port)
- External opto-isolated I/O interface with:
• 4 independent analog inputs
• 4 independent analog outputs
• 4 remote control inputs
• 6 dry contacts outputs - 24 V Power supply PLUS extended temperature range 0-50°C for utilization without air conditioner
- Continuous indoor and outdoor air quality monitoring
- Stationary and mobile AQMS laboratories
- Quality control in food and beverage industry
- Industrial fence-line monitoring
- Continuous emissions monitoring (CEM) by dilution
- Medical gases: fail-safes and quality control
- Background (urban or suburban), Rural, Traffic, Kerbside measurement campaigns and monitoring studies
- Laboratory and field studies on CO effects
- Measured parameter: CO (CO2 optional)
- Technology: Gas filter Correlation – NDIR
- US-EPA Approval / QAL 1 Certification: YES
- Measurement: 0-50 ppm (0-300 ppm upon request)
- Measurement units: ppb, ppm, µg/m3 (user-selectable)
- Lower Detectable Limit (2σ): 0.05 ppm
- Noise (σ): 0.025 ppm
- Zero drift: < 0.1 ppm/24 hours
- Span drift: < 1%/24 hours
- Linearity: ± 1% FS
- Sample flow rate: 1L/min
- Sampling pump: Internal
- Temperature range: +5 to +40°C (up to 50°C optionally)
- Data storage: 1 year
- Included I/O: 1LAN/3USB/WIFI/2DRY
- Weight (Kg): 8
- Dimensions mm (LxWxH): 483 x 606 x 133
- Chassis: 19″ Rack, 3U
- Power supply: ‘100~250Vac, 50/60Hz + ground (24V optionally)
- Pressure and temperature compensation: YES
COMPLIANCE WITH:
- EN 14626 (2012), EN 15267, 2008/50/EC, 40 CFR PART 53 SUB B & SUB C
- QAL 1 certified by the TÜV to N° 0000050626
- U.S. EPA approved as compliant with RFCA-0915-228
