Longone - Chamber Filter Press

Longone - Chamber Filter Press

FromLongone Equipment Inc.

SHARE

The chamber filter press represents a state-of-the-art separation technology product that seamlessly integrates mechanical, electrical, and hydraulic systems. Comprising five main components—frame, filter section (including filter plate, membrane plate, and filter cloth), plate pulling mechanism, hydraulic controls, and electronic control unit—this equipment is designed for optimal performance. The frame of the machine serves as the structural backbone, composed of thrust plates, pressing plates, cylinder blocks, and a main beam, ensuring stable mechanical performance. The filtration unit is a sophisticated assembly of filter plates and cloths arranged to form multiple independent filter chambers, achieving high-pressure separation with maximum filtering pressure reaching 4.0 MPa (40 Bar). Constructed from reinforced PP filter plates, the system boasts high strength, low weight, and excellent resistance to acids, alkalis, and corrosion. Enhanced with an automatic pulling plate mechanism and a well-integrated hydraulic system equipped with various control valves, the chamber filter press provides high efficiency and operational ease. Optional auxiliary systems such as mobile devices, filter cloth rapping devices, and automatic cleaning devices are available to meet specific user requirements. The electronic control system centralizes and automates the entire operational process, ensuring high-quality performance. Longone's filter presses are widely used across diverse industries including pharmaceuticals, food production, chemical processing, smelting, non-metallic minerals, new energy, and environmental protection.

Most popular related searches

chamber filter press

membrane filtration plate

plate cloth filter

polypropylene filter

Chamber filter press is easy to operate and maintenance as the filter press is compressed by the hydraulic jack system and mechanical locking. The maximum filtering (squeezing) pressure is 4.0 Mpa(40 Bar). The filter press adopts the reinforced PP filter plates. The filter plate featured in high strength, light weight, anti-corrosive, acid and alkaline resistant, non-toxic and odorless is molding pressed with patent technology.

The chambe filter press is a technologically advanced separation machinery product that integrates machinery, electricity and hydraulics. lt consists of five parts: frame part, filter part (filter plate, membrane plate, filter cloth), pullingplate part, hydraulic part and electrical control part.

The frame part is the main body of the machine, used to support the filter mechanism and connect other components. lt is mainly composed ofthrust plate, pressing plate, cylinder block and main beam.

The filtration part is composed of filter plates aranged on the main beam in a certain order, filter cloth sandwichedbetween the filter plates, and membrane (membrane models have) filter plates. The filter plates and filter cloths (andmembrane filter plates) are arranged altemately to form several independent filter units - filter chambers.

The automatic pulling plate part consists of a variable frequency motor (hydraulic motor, manipulator,transmissionmechanism and pause dewice.

The hydraulic part is the power device that drives the pressing plate to press or loosen the filter plate. t is equippedwith a plunger pump and various control valves.

The electronic control part is the control center ofthe entire system.

It is easy to operate and maintenance as the filter press is compressed by the hydraulic jack system and mechanical locking.

The maximum filtering (squeezing) pressure is 4.0 Mpa(40 Bar).

The filter press adopts the reinforced PP filter plates. The filter plate featured in high strength, light weight, anti-corrosive, acid and alkaline resistant, non-toxic and odorless is molding pressed with patent technology.

The frame of filter press is weld steel structure with stable mechanical performance, delicate type and attractive appearance.

The filter press can be configured with related auxiliary systems. It can be equipped with a mobile device, achieving automatic pulling of the board. It can be equipped with a filter cloth rapping device to completely remove the filter cake. It can be equipped with a filter cloth cleaning device, which automatically cleans the filter cloth and improves filtration efficiency. The choice of auxiliary system depends on the specific needs of the user.

The filter press is equipped with an electronic control system, achieving automatic control of operating procedures.
