CNC Turning Capabilities
With turning capabilities ranging from ~.020” to 78” in diameter, Aerodyn can handle a very large range of part sizes and geometries.
Most popular related searches
through-spindle coolant
5-axis milling machine
turning machine
milling machine
vertical lathe
CNC turning service
vertical mill
spindle
horizontal mill
- Okuma VTM 2000YB – A vertical mill-turn machine with max turning diameter of 78.74″, max turning height of 55.12″, X-Y-Z travel of 62.99″x63″x55.12″. Milling spindle: 10,000rpm with high pressure through-spindle coolant. Full 5-axis contouring milling and on-machine probing.
- Okuma V100R – A vertical turret lathe with max turning diameter of 48″ and max turning height of 35″. Live 3-axis tooling.
- DMC DL100VM – A vertical turret lathe with max turning diameter of 37″ and max turning length of 33.5″.
- Okuma LU400 – A horizontal 4-axis lathe with max turning diameter of 24″, distance between centers of 78.74″, chuck weight of 770lbs, and weight between centers of 1320 lbs.
- Okuma LU300 – A horizontal 4-axis lathe with max turning diameter of 14.57″ and distance between centers of 33″.
- Okuma LB3000 – A horizontal lathe with max turning diameter of 16.14″ and max turning length of 19.69″.
- Okuma LB2000 – A horizontal lathe with live tooling, bar feeder, max turning diameter of 16.93″, and max turning length of 11.81″.
- Okuma Multus B300W (x2) – Two horizontal 5-axis mill-turn machines with max turning diameter of 24.8″ and distance between centers of 35.43″. These machines utilize 10,000rpm spindles and 1000psi through spindle coolant.
