Schunk Sonosystems GmbH
Model Kobra-EL -Cooling Technology
The Kobra-II is used for gas-tight welding of copper tubes in refrigeration circuits. The machine has an output of 3 kW and is suitable for tube diameters of up to 10 mm with a wall thickness of up to 1.0 mm. An optional barcode scanner is available for the traceability of individual welds by serial number. The handles can be selected from several different variants.
Most popular related searches
cooling system
process control monitoring
compressed air
inductive sensor
process monitoring
welding air
interface monitoring
- Power: 3 kW
- Frequency: 20 kHz
- interface to manufacturing executions systems (MES) possible
- optional upgrade of the controller USC-5 to Kobra-III welding head
- compressed air supply: 6,5 bar
- power supply: 230 V, PE
- inductive height sensor
- very robust construction
- Windows-based system with user-friendly software interface
- dynamic process control (monitoring of height, enery and time)
- low operating costs
- import/export function for copper tubes dimension and welding files
- multiple user languages
