XuYan - Model XY-PS600 -Digital Pressure Switch

• Dual relay, Output signal NONC
• 4-Digits LED Display.
• Power supply 24VDC; Optional 220VAC
• Accuracy level: 0.25%FS；0.5%FS
• Multi-unit convert Bar KPa PSI
• High precision, quick response time, stable and easy setting up

XY-PS600 is an Intelligent Digital Pressure Switch Box, whole metal shell, with integrating pressure measurement, display and control function. It has a variety of excellent functions, such as one-button reset, Multi-pressure Unit Converting and it’s easy to reset setting, adjusting and installation.

Two relays are built in, this series of digital pressure switches have dual relays, which can be set up two ways of normally open and normally closed alarm points separately, also are able to control two ways of high and low pressure of air or liquid, in addition, it is with one key reset, at the same time, calibration, shifting display unit, setting return difference and other option functions.

The intelligent pressure switch is equipped with a high-precision instrument amplifier to amplify pressure signal, built-in temperature compensation sensor, is the high precision equipment for detecting and monitoring pressure and liquid level.

XY-PS600 Intelligent Digital Pressure Switch box has stable performance and can be widely used in the automatic system, mobile working machines, Medical equipment, pump, compressor, Energy and water treatment, Agricultural equipment, test system, hydraulic system and pneumatic system.

• Model: XY-PG600
• Gauge Pressure Range: 0…10...50...100KPa
• Mirco Pressure Range: 0~1…2…6…10…16...25…50…100…250…400…600Bar
• Vacuum Pressure Range: -100~0KPa
• Overload Capacity: ≤10MPa  200%; >10MPa 150%
• Measurement Medium: Gas or oil or other Liquid with Compatibility of  SS 304 or 316
• Accuracy Level: 0.25%FS;0.5%FS;
• Long-Term Stability/Year: Typical: ±0.2% FS;
• Alarm Point: Any pressre @whole measurement range
• Output: Relay; NONC
• Relay Capacity: 220VAC 5A; 24VDC 5A
• Display: 4 digits LED
• Operating temperature: -40~85oC
• Compensation: -20~60oC
• Power Supply: 24VDC or 220VAC and 380VAC are optional
