RockBuster - Model RBI-400 -Drill Rigs

SPECIFICATIONS

• 105hp Diesel Power, Water Cooled, 12V Electric Start

• Hydraulic System: 50 gpms, 3480 psi (240bar)

• Top Drive: Gear Box - Through Spindle, 2” Top Inlet
  Rated for 350psi (optional upgrade to 750psi)
  2-3/8” IF Pin Down (other optional threading available)

  Top Mount Hydraulic Breakout

• Drill Motor: Two Speed
  Speed 1: 0-75 rpms with 3165 ft-lbs (4291Nm) of Torque
  Speed 2: 0-150 rmps with 1582 ft-lbs (2145Nm) of Torque

• Push Down: 15,000 lbs (@100rpms)

• Pull Back: 25,000 lbs (static)

• Mast: 12ft Stroke

• Mud Pump: Centrifugal 4” suction x 3” discharge with 13” Impeller
  Up to 50psi and 400gpm
  Circulation Bypass
  (Other Mud Pump Options Available)

• Mast Extension: Mast more than 21feet

• Lifting Winch: 4500 lbs Capacity (other options available)

• Outriggers: Three (3) Manual Screw Jacks with 10,000 lbs capacity each (optional Hydraulic jacks)

• Approximate Weight: 8000 lbs without any drill rods in the rod rack

• Mobility: Platform fabricated in house with high quality/high-grade American steel
  Mounted on dual axles with 14,000lbs Capacity and 16” rims.
  2-5/16” Ball Coupler (other options available)
  Rod Rack capable of holding up to 400 feet of 2-3/8” x 10ft (3m) Drill Rod

  Crawler and Truck Mounted Options Available
