Dry Cooling Tower
Dry Cooling Towers is also known to be indirect closed loop cooling tower. Dry Cooling Towers has been structured in an way that water is cooled by the circulation through the finned tubes, which results in heat transfer. Due to this Dry Cooling Towers doesnt need much of water as the water is not loosed. We manufacture from low capacity to high capacity depends on customer. We also deal Overseas Clients. The hot water from any equipment can be sent to the inlet of the Dry Cooling Tower & that hot water get Cooled and Cold water outlet from the Dry / Coil is connected to the pump, which pumps the cold water to the equipment to transfer the heat from the equipment with less Evaporation loss, Maintenance free, No need of raw Water tank & 100% free from decaling.
Dry cooling tower is made up of no of wounded coil.Coil has designed based on the technical specifications like flow rate and temperature . Coil tube material is copper tube, Stainless steel ( 304 series) and brass tubes.Copper tubes has been bend at the two side of the corner.In this particular bending area make radius form, so water goes to passing continuously without interruption.
All the tube connected area must welded by brazing.All the welding done by qualified welders only. Finns are wrapped on the tubes.Finns wrapped based on heat transfer area.So cooling performance will be very high.
- Casing: HDGS (Option: Galvanized Steel or SUS304)
- Frame: HDGS (Option:SUS304)
- Axial fan: Hub: Cast Iron Blades: Aluminium Alloy
- Drive: Directly shaft transmission drive
- Casing: closed cooling tower dedicated motor
- Coil: Seamless copper tube expand into aluminium plate fins
DRY Cooling tower is designed to special industry application which wet cooling equipment are not available working condition. Such as air conditioning system glycol water solution, Hospital equipment, computer room installations and their applications include industrial water cooling systems, furnaces, plastic moulding machines, transformers, engines and generators etc.
Modular structure, use the high quality of zinc magnesium aluminum material (304 or 316 stainless steel for option), which is standardization made by Z600 galvanized anti-corrosion processing. After passivation treatment, cooling tower can withstand water PH value 6.5-9.0 . At the same time, the component design strength can bear the windpressure of 1440 Pa, Protected the product quality and ensured stablerunning. Equipment can be ordered according to singlecell or multi cells.
Using high quality Q235 steel plate with corrosion prevention painting , high strength,strong anti-corrosion ability, beautiful appearance, smooth and easy assembly, etc.
AXIAL FAN:
Using the centrifugal fan, through static and dynamic test of production Process, to meet the cooling tower heat transfer performance under the Premise of maximum noise reduction.
MOTOR:
Using closed cooling tower dedicated motor, IP55 protection grade, insulation class is F,suitable for hot and humid environment to run for a long time. Products comply with IEC international standards, with high efficiency, low noise, long life, reliable operation, etc.
ALUMINIUM COIL:
Seamless copper tube expanded into collared aluminium plate fins.Surface rate Fin/cooper is more than 20. Ensure the excellent Performance of heat discharge. Hygrophilous aluminum fins ensured well performance and long service life.Copper coil are seamless and tested under 1.6Mpa comressed air under water.
