DistaView - Model KLC -Electrically Operated Controlled Device
The KLC provides proportional control. It does not require electrical connections, sensors or electrically operated controlled devices. KLC operates on plant air only. The KLC is a device which uses plant air to function as a bubbler sensor and controller within a single enclosure. It does not need another converter and provides direct-acting, modulating pressure to the system’s proportional control valve. Its single module design and air conversion process is simple and there are specific advantages over direct contact pressure transducers, ultrasonics, lasers, probes, ball floats, or load cells.
Most popular related searches
load cell
pressure transducer
control valve
ultrasonic probe
proportional valve
liquid level monitoring
liquid monitoring
ultrasonic transducer
fouling
pressure probe
- Typical Applications
- Schematics of Various Systems Applications
- Movies - Choose the best format for your computer
- KLC Pump Movie - smaller file for slower connections
- KLC Pump Movie - larger file for faster connections
Some of which are:
- It needs no electrical connections nor external sensors.
- There are no moving parts.
- The sensing tube is not vulnerable to fouling like typical ball floats or probes.
- The tube just needs a small opening, therefore it can fit almost anywhere.
- There is no need for clearance to accommodate linkage movement as required by ball floats.
- The output is a direct acting pressure at either, 0 to 35 psi or 0 to 100 psi.
- It can serve almost any diaphragm or cylinder actuator.
Its main application is to monitor liquid levels in reservoirs where fluids are continuously flowing in and out to satisfy a process.
