Envea - Model Leak Locate 662 -Filter Performance Monitors
FromENVEA
The LEAK LOCATE 662 is a digitally networked, multi-compartment baghouse monitoring system providing remote observation of the condition of bag and cartridge filters.
Most popular related searches
wet electrostatic precipitator
bag filter cartridge
cartridge filter
filter monitoring
wet electrostatic precipitation
filter cartridge
electrostatic precipitator
electrostatic precipitation
bag filter
ceramic filter
- Reliable monitoring of leaking and broken bags in dust collectors
- Sensor configured remotely via controller
- Manual sensor Drift Checks (zero and span)
- Probe Check (Insulator Short-Circuit Check) option for improved data integrity
- Digital display and optional graphical display to view live data and monitor bag cleaning cycle
- Reduces filter maintenance intervals, process down-time and filter costs
- Particulate monitoring in stacks after bag filters, cartridge filters, cyclones
- Variable velocities within range 4-30m/s (typical bagfilter velocity ranges), constant velocity required outside this range
- Incineration
- Metals (e.g., Steel/Aluminium)
- Minerals (e.g., Cement/Gypsum)
- Chemicals (e.g., Detergent/TiO2)
- Food (e.g., Milk Powder/Tobacco)
- Power (e.g., Boilers/Biomass)
- Measured parameters: Dust
- Technology: ElectroDynamic® Advanced Probe Electrification
- Measurement/Monitoring capability: 0-500 mg/m³*
- Stack/Duct diameter suitability: up to 4m
- Flue gas temperature: up to 250°C
- Baghouse: YES
- Cartridge Filter: YES
- Ceramic Filter: /
- Coalescent Filter: /
- Cyclone: /
- Electrostatic Precipitator (ESP): /
- Wet Electrostatic Precipitator (WESP): /
- Wet Scrubber: /
- Sensor variants: Stainless Steel
- Fully insulated PTFE coated
- QA checks: YES
- 0-250°C standard: Functionality and QA Checks
- Drift check (zero and span), Probe short circuit check option: Inputs
- 4x Digital inputs, 2x 4-20mA inputs: Outputs
- Optional RS232, RS485 (Modbus), 2 x Digital Alarm and 4/20mA: Display
- Two Line Digital display and Bar graph Large Graphical Bag Pulse Display (option): Air Purge
- Option
Certificates:
- US EPA MACT Compliant BLD
- Ex Zone 22
