Inowa - Model H -NS 3-40 -Filterless High Performance Oil Separator System
The "System H" Separator in round construciton is the core article of the INOWA product range and at the same time the mostly used type of the whole "System H" construction range. This construction type covers a large part of application areas in different branches.
Keyfacts
System Descripton: INOWA System H
Construction: Filterless High-Performance Separator in compact construction for the soil-installation
Design: Monolithic steel-concrete basin , round construction
Proved and CE-marked acc. to EN 858-1, meets all
requirements acc. to DIN 1999-100 and DIN 1999-101.
Registerd acc. to ÖNORM B5101, DIBt-Allowance
Building-Authority Allowance Nr. Z-54.3-409
Other usual descriptions: Coalescence separator, light liquid separator
- Absolutely filterless without the use of coalescence material
- Inflow lock and density-independent initiating mechanism, no warning device necessary
- Automatic oil withdrawal in to a separate oil container (comes up to those requirements acc. to DIN 1999-101)
- Integrated sampling acc. to DIN 1999-100
- Simple density check acc. to DIN 1999-100, 15.3.3
- PEHD-Inliner instead of customary coating
The INOWA System H in round constructon is used in various application areas like e.g.:
- Petrol Stations
- Biodiesel-Refuelling Stations
- Car Dealers
- Car Garages
- Washing Places
- Car-Wash Plants
- Conveyor Tunnels
- Transport Companies
- Scrapyards
- Agricultural Machinery Companies
- Earth-Moving Companies
- Trade and Industry
- Power Stations
- Trafo Stations
- Military Facilities
- Funiculars
- Public Transport Companies , a.s.o.
