GFE - Model OCTO+ -Fire Alarm Control Panel
The OCTO + Fire Alarm Control Panel is built on the pedigree of the worldwide known JUNO NET. Now featuring a fully peer-to-peer, multi-master networking solution this new ‘Chameleon Network’ solution offers extreme resilience in very large distributed systems. In the Chameleon Network system, each network NODE+ retains information about the whole system in its internal memory, which means that in the unlikely event of a communication loss, the performance of each individual NODE+ is unaffected.
Most popular related searches
fire alarm control panel
fire alarm control
fire alarm
fire control panel
fire alarm panel
fire panel
remote monitoring
anthracite
- POWER SUPPLY RATING: 90V AC to 230V AC
- PRIMARY DC SUPPLY: 28.5V DC @ 2.4 A (Max.)
- SECONDARY SUPPLY: 21.6V DC (Min.) – 27.2V DC (Max.) – Battery charger: 27.5V DC
- BATTERIES (INTERNAL): 2x 12V 12 AH (Max.)
- QUIESCENT CURRENT (NO DEVICES): 64mA
- AUX POWER OUTPUT: 2x 24V DC 300mA / up to 1x 24V switched out
- MAXIMUM LOOP OUTPUT CURRENT: 1-4 loop – Max. 165mA per loop quiescent / Max. 900mA per loop peak
- LOOP TOPOLOGY: Class A or B
- DETECTOR CABLE: Firetuf 2 x 1.5mm (Max. 1200m) or 2 x 2.5mm (Max. 2000m)
- CONVENTIONAL SOUNDER CIRCUITS: 500mA for conventional sounder circuits a+b
- AUX. RELAYS FIRE: 2x rated 2A @ 30V DC resistive / 0.5A @ 120V AC resistive/ 0.25A @ 240V AC resistive
- AUX. RELAY FAULT: 1 rated 2A @ 30V DC resistive / 0.5A @ 120V AC resistive/ 0.25A @ 240V AC resistive
- GRAPHICAL LCD DISPLAY: 240×64 pixels blue backlit
- COMMUNICATION CHANNELS: 3x configurable communication ports
- BMS OUTPUT: ODYSSEY (Graphical software), TCP IP-WEB (remote web monitoring), MODBUS RTU, ESPA 4.4.4
- SOFTWARE CONNECTION: USB type B
- EVENT LOG: 10,000 messages
- OPERATING / STORAGE TEMPERATURE: -10ºC to 50ºC
- HUMIDITY: Max. 85% RH Non-Condensing
- INGRESS PROTECTION / MATERIAL: IP30 / ABS
- DIMENSIONS: 345 (L) x 375 (H) x 139 (W) mm
- WEIGHT: 7,5 Kg – 10,5 Kg (inc. battery)
- COLOUR: White (RAL 9003), Red (RAL 3001) or Anthracite (RAL 7016)
