Sinap - Flat Sheet Membrane

Technological Advantages of SINAP FS Membrane

Excellent chemical stability
SINAP flat sheet membrane use PVDF as material which with very good chemical stability, fouling resistance and mechanical strength in nowadays membrane material. It is the most widely used membrane material in wastewater treatment in the world.

Excellent permeate flux and permeate quality
Pore size of SINAP flat sheet membrane is less than 0.1 microns, and with advanced membrane technology increase the effective orifice area of the membrane surface then lead to excellent permeate flux and permeate quality.

Excellent fouling resistance
S1NAP membrane is a super micro membrane with asymmetric structure. This structure has advantages of low membrane resistance, good fouling resistance. Large particles of pollutants will not enter the membrane under the erosion of air Small particles into the membrane will not be stranded in the membrane pore and quickly flow through the large hole out of the membrane.

Comparison of Flat Sheet Membrane and Hollow Fiber
Adapt higher concentration of activated sludge {MLSS is greater than 8000mg / L). Membrane surface does not plot the mud and no lose of effective membrane area. Air and water erosion on the membrane surface remove the membrane surface dirt Because the membrane is firmly welded on high-intensity support plate, it does not appear the phenomenon of broken wires as hollow fiber so permeate water quality stable. This is especially important when processing in the subsequent process-depth NF or RO.
