GattaFluorescent Beads

SHARE

Fluorescent beads are important microscopy tools which can be used for calibration of microscopes, particle tracking or quantitative determination of point spread functions especially in STED microscopy. Particularly for the last point a small structure size keeping a high brightness is an immense advantage. Products from the GATTA-Bead series fulfill this requirement perfectly with a diameter of only 23 nm. Additionally, they show a clearly improved homogeneity and flexibility compared to other beads. We offer GATTA-Beads in the colors red (ATTO 647N), orange (ATTO 594), green (ATTO 542) and blue (Oregon Green 488). Moreover, we offer alternative dyes which are indicated on the table below.

Most popular related searches
  • Setup calibration
  • 2D STED measurements
  • 3D STED PSF distillation and deconvolution
  • Tracking and drift-correction
  • Size: d = 23 nm
  • Brightness: the highest brightness density
  • Homogeneity: super small size and intensity distribution
  • Flexibility: change color or add chemical groups
  • Color: red
  • Available fluorophores: ATTO647N
  • Alternative fluorophores: Abberior STAR 635P
  • Recommended laser source: 630-650 nm
  • Diameter: 23 nm
  • Surface density: ≈ 1/µm²
  • Price (sample on glass slide): 300,-€
