Model YM-WX80 -Fully Automatic Baler

• Main Motor Main motor:22kw
• Motor for wire hooking machine:1.5kw
• Motor for water pump:2kw
• Oil Cylinder D180mm*d140mm
• Feed Opening Size L1100mm*W730mm
• Bale Size W800mm*H800mm*L
• Bale Weight(Cardboard) ≈300-400kg (5-8min/ bale)
• Packing Density 400-500kg/m3
• Number of Tying Wire 3
• Water Cooling System 8 ton Water tower or air cooling fan
• Covering Area L7200mm*W4000mm*H2400mm
• Machine Weight Machine body is approx. 8000kg
• Applications This model is suitable for paper&cardboard manufacture

Thanks to the stable system, unique design and perfect device, Yongmao baling machines possess high performance, high efficiency, and good qualities. They are easy to operate and save energy.

• System stability
  Hydraulic circuit system is high-performance, low noise and no vibration
• Save energy
  Unique decentralized-scissors design. High efficiency and prolong machine`s life cycle.
• Reduce error rate
  Automatic line bundle device accelerate the running speed, simply the cleaning process.
• Adjustable length
  Baling length can be changed. Make it more tight in need.
• Package accuracy
  Hydraulic threading device makes the packing accurate and hard to loose
• Simple operation
  PLC control system is easy to operate. Save your time and labor.
