Friend - Model FDT-0294 -Fully Automatic Open Flash Point Tester

SHARE

The automatic open flash point tester is designed and manufactured according to ASTM D29, GB / T3536-2008 standard "Petroleum Product Flash point and ignition point Measurement Method (Cleveland Open cup method)". For oil products with open cup flash point higher than 79?.

Most popular related searches
flash point testing
flash point
automatic flash point testing
open cup flash point
oil analysis system
flash testing
digital temperature controller
dynamic calibrator
pressure sensor automatic
oil analysis
  1. Color LCD screen display, touch operation, real-time tracking of the function curve of heating display and test time, operation real-time prompt function;
  2. with multi-point dynamic calibration function and static calibration function (take care of the accuracy of the results at each temperature point);
  3. unique automatic lifting arm design, no need to manually install the flash point cup cover, after the cup cover automatically tilt, convenient cleaning;
  4. the heating system can provide uniform heating, and the heating rate meets the standard requirements;
  5. built-in inlet pressure sensor, can automatically correct the result value;
  6. the ignition method adopts gas ignition, equipped with a small liquefied gas tank, the ignition temperature is stable, high repeatability, and convenient
  1. Range of temperature control: room temperature ~400?; resolution: 0.1?
  2. Temperature increase speed: initial temperature increase: 14 (? / min) ~17 (? / min) End-stage temperature increase 5 (? / min) ~6 (? / min)
  3. detection method: ion ring and thermoelectric element gas double detection
  4. ignition mode: gas ignition
  5. Display mode: touch screen display, software operation
  6. repeatability: ± 2?
  7. data output: built-in printer printing, USB interface, can directly be exported through the U disk data
