Felix - H2S Analyzer
The H2S analyzer provides a dependable, accurate and convenient method of measuring hydrogen sulfide in levels commonly required for Ambient Air monitoring, offering ranges from 0-50 ppb to 0-10 ppm. The analyzers convert sulfur gases to sulfur dioxide and measure concentrations using fluorescence technology.
The analyzer is equipped with an internally mounted low temperature converter which converts H2S at a closely controlled temperature setting of 315 °C, leaving other gases unaffected. TRS components (typically, H2S, methyl mercaptan, dimethyldisulfide and methyl-disulfide) are all converted to SO2 at this temperature, with efficiency greater than 98%.
Sample gas drawn into the analyzer first passes through a scrubber which removes all traces of sulfur dioxide. The converter then converts the components of interest to SO2. The resulting concentration for SO2 is then measured by fluorescence.
- Standard two year warranty
- 0-50 ppb to 10 ppm (101E), 0-50 ppb to 10 ppm
- Microprocessor controlled for versatility
- Auto ranging, dual range and remote range selection
- Built in self checks and diagnostic capabilities
- Bi-directional RS232 allows remote reading or operation (optional RS-485 or Ethernet)
- Digital status outputs provide instrument condition
- Auto Zero System
- Adaptive signal filtering optimizes response time
- Temperature & pressure compensation
