HCC - Model 4000/71-GR -Hydraulic Dredger
Productivity оf the pulp: 4000 m3/h. Productivity оf the soil (hydraulic deposition of soil category 1): 750 m3/hour; 6000 m3 for the shift(8 hours). Dimensions: length 25 m width 8 m, height 5.0 m. Weight: 65 tons. The dredger is equipped with an arrow. Suction pipe length - 12 m type `polygon` with hydraulic washing-out (jet), the water supply is 350 m3 per hour with hydraulic drop of 120 m, pump capacity is 225 kWt.
Most popular related searches
- Slurry pipeline: 100 m (including - 50 m floating, 50 m - beach), diameter 600 mm.
- Engine: CAT DM6490 (capacity 1,900 liters / power, fuel consumption is 400 liters/hour, speed is 1900 rev/min) or equivalent.
- Diesel power station GPR-500 power 350 kW, fuel consumption 100 lit / hour.
- Pump: GRAU 4000 /71. Pump specifications: 20 inch/18 inch; Output 20% soil per hour, the pressure of the water column - 71 m, max power - 1300 kW with a head of water column of 71 m, speed - 500 rpm/min.
- Dredge this modification lifts the soil from the bottom of water basin of 1.5 - 11 meters, pushing for the slurry pipeline up to 3500 m.
- Energy supply: self-contained supply. Movement with the help of winches – 4 power units 5 kWt.
- The enterprise guarantees the operation of the equipment for 1 year or 1800 Moto hours.
- Term of manufacturing is 14 months. Complete package of documents.
