Hydraulic Filter With Regulator ...

Hydraulic Filter With Regulator Controller

FromACAR MAK SAN Makina Sanayi

SHARE

Smart Filter is the top level of Hydraulic Automatic Filtre technology that ACRV reached. Compared to other produced filters for same aim in sector. SMART filter design which is high engineering product, has superior features. This model can be used alone in open channels as the filtering area is wider. Due to the excess of permeability, it becomes contaminated later than the eco model.

Most popular related searches

coarse screening

pressure cleaning

filter cleaning system

pressure regulator

cleaning nozzle

self-cleaning filter

Self-cleaning ACRV Filter systems; It can be used in industrial plants, agricultural irrigation systems alone or as a tandem, as well as working with additional equipment such as hydrocyclone, algae filter, suction filter, and primary filter.
Control systems with pressure regulator can be adjusted with the pressure difference.
In electronically controlled systems, it can be adjusted both with the pressure difference formed and at the desired periodic times.
The choice is optional.
It is made of corrosion resistant materials.
It is manufactured to operate at maximum 10 bar inlet and minimum 1.5 bar outlet pressure.

Thanks to the improved regulator control system, the cleaning time can be adjusted.
Even at lower pressure, it can work efficiently (1,5 bar).
It can complete self-cleaning by draining less dirty water.
Being able to clean itself in a shorter time.
Maintenance costs are lower and control is simple.
The cleaning nozzles have higher vacuum power.
Some reactions can be observed during cleaning.
Rotor torque is higher.
Ability to clean the sieves with both nozzle and brush.
The coarse sieve really supports the fine screen set (1500 microns).
Displaying coarse screen pressure, fine screen pressure and clean water pressure separately.
Highest performance in harsh conditions (very heavy pollution).
The filter is able to protect the control system from possible air pressure.
Ergonomic Structure.
Above all ..! It is designed and manufactured by ACAR-MAK-SAN and it is under the assurance of ACAR-MAK-SAN.

Automatic filter bodies are made of carbon steel and stainless steel, the choice is optional.
It provides filtering range up to 50 to 200 microns.
As soon as the pressure difference reaches the specified value, it starts cleaning itself.
It cleans itself without interrupting the flow of water in a short time and the water flow continues in the system.
Thanks to its modular and simple structure, it offers solutions in different capacities. (16m³ to 320m³)
Our products can be mounted linearly on the trailer, on the ground and at the corners when requested.
After our products are tested at 10 bar pressure, chemical metal cleaning is performed.
Then it is painted in the furnace with a zinc-based primer and a finish electrostatic paint.
