Whitley - Model H25 -Hypoxystation
The H25 Hypoxystation creates hypoxic and anoxic conditions within a controlled and sustained workstation environment. For cell and tissue culture researchers who want a small chamber with stable conditions in which to accurately control oxygen, carbon dioxide, temperature and humidity, this workstation is ideal.
With the H25 you can control oxygen in 0.1% increments up to 20%; carbon dioxide in 0.1% increments up to 15%; and relative humidity up to 80%. This provides a great deal of flexibility in your research and confidence in your results.
This Hypoxystation can accommodate 145 x 96 well plates while still leaving more than adequate space to process samples. This workstation is equipped with sleeved ports and has a built-in, rapid airlock that can accommodate 3 x 500ml Duran bottles.
If you need to aspirate biological liquid waste from inside the chamber, order with a Vacuum Take-off Port and the Whitley AsPROvac for the perfect package. This workstation is also available with a motorised height adjustable trolley, developed specifically to raise and lower the workstation to suit different users.
- Built-in rapid airlock allows items to be transferred into the workstation atmosphere in 20 seconds and the doors are interlocked so cannot be opened simultaneously.
- Colour, touchscreen control panel for ease of use and for visual display of parameters such as oxygen level, carbon dioxide level, temperature, humidity, and airlock cycle status.
- Low gas consumption.
- Fully integrated gas control avoids bulky add-on systems and reduces the need for additional bench space.
- Optional 15cm single plate entry system fitted to the side of the workstation.
- Optional data download facility and oxygen profiling.
- Can be fitted with a range of cable glands and other options to tailor the workstation to your requirements.
- Capacity (litres) : 180.00
- Airlock Size (litres) : 6.00
- Porthole System : Manual
- Footswitch : Wireless
- Auto Sleeve Gassing : Available
- Internal Mains Sockets : Available
- Inspection Lamp : Available
- Single Sample Entry : Available
- Data Logging : Available
- Airlock Cycle Time (seconds) : 20
- Extra Cable Glands : Available
- Removable Front : Unavailable
- Trolley Available : Available
- O2 Profiling : Available
- Temperature Range : 5°C above ambient to 45°C
- Touchscreen Control : Yes
- Remote Access : Included
- Dimensions (W/D/H mm) : 790 / 720 / 710
- Weight (lbs/kgs) : 169 / 77
