Chemisonic - Model ULP100 -Lab Ultrasonic Processor

The ULP100 is used in particular in medical, biological or chemical laboratories. This device is most suitable for the ultrasonication of very small as well as medium-sized samples. For volume samples from 5mL up to 500mL we offer three replaceable probes with diameters from 3 to 8mm. This device is perfectly suited for handheld operation with its lightweight 0.7kg, but it can also be operated at a stand.

• Thumb-switch or continuous operation
• Handheld or stand-mounted
• Simple and effective operation
• Probes are available three different sizes: 3mm and 6mm,8mm
• Three power adjust: From 60%, 80%,100%
• Replacement converter
• Stand with clamp

• Output Power: 100watt
• Output Frequency: 20KHz
• Adjustable Pulse On/Off: 1 Second to 99 Second
• Programmability: 1
• Programmable Timer: 10 hours
• Program Export: NO
• Remote Upgrade: NO
• Input voltage: 220V-240V, 50/60Hz
• Rated current: 6A
• Capacity: Up to 50ml
• Dimensions: 347x290x125mm

1. CS20-HR1302: 5/64"(2mm)

• Tool head with thread 1/4-28;
• Two transformations;
• Amplitude 200um
• Large head diameter 13mm

2. CS20-HR1303: 1/8"(3.2mm)

• Tool head with thread 1/4-28;
• Two transformations;
• Amplitude 200um
• Large head diameter 13mm

3. CS20-HR1306: 1/4"(6.4mm)

• Tool head with thread 1/4-28;
• Large head diameter 13mm
• One time transformation ratio;
• Amplitude 120um
