Silver - Model SHD -Magnetic flow meter

Measurement Principle • Faraday's Law of electromagnetic induction • Measures conductive liquids (>5 μS/cm) Key Features • Accuracy: ±0.5% of reading (±0.2% optional) • Zero moving parts maintenance-free design • Bi-directional flow measurement • IP68 submersible option available Applications • Water and wastewater treatment • Chemical and process industries • Pulp and paper production • Food and beverage processing Technical Parameters • Sizes: DN15 to DN3000 • Pressure Rating: PN10-PN40 • Temperature Range: -20°C to +180°C • Outputs: 4-20mA, pulse, RS485 (Modbus/HART) • Power: 24VDC/85-265VAC • Electrode Materials: 316L, HC, HB, Ti, Ta • Liner Materials: PTFE, PU, rubber, ceramic Certifications • CE, RoHS compliant • Explosion-proof versions (Ex d, Ex i)
