WSF - Model WSFSGE2DCI51-24-30W -Micro External Gear Pump

Precautions

1. It is strictly prohibited to transport or clean solvents and materials containing dichloromethane, tetrahydrofuran, butyllithium, and dimethylacetamide.
2. Before disassembling the pump, please cut off the power supply to the motor and completely release the pressure in the pump.
3. Do not change the components of the pump and motor. Any changes may reduce the pressure rating of the pump and cause harm to people.
4. A sealing ring, sealant or raw material tape must be placed on the inlet and outlet joints of the pump, especially at the inlet. If there is air leakage, the liquid will not be sucked, and the noise will even increase.
5. It is prohibited to transport media containing particles, and it is prohibited to run idling/dry.

• The model is small in size and compact in structure.
• PEEK gears and bushings are resistant to organic solvents, corrosion, high temperature, and high strength and friction resistance.
• High pressure and large flow
• The flow rate is fixed and cannot be adjusted
• Intermittent work, no continuous work
• The brush motor can work for about 5,000 hours, and the normal service life is 2-3 years.
• Safety and environmental protection levels can meet international standards (CCC, ROSH, CE)

Name: Specification

• Model: WSFSGE2DCI51-24-30W
• Displacement: 2ml/rev
• Traffic: 1800ml/min
• Pressure: 5 bar
• Motor: DC brushed motor
• Rotating speed: 3000rpm
• Motor Power: 30W
• Rated voltage: 24V
• Rated current: 1.6A
• Import and export direction: Both sides of the pump body
• Import and export thread: G1/8
• Temperature resistance range: -10? ~ 50?
• Noise: 80DB
• Material: Pump body 304, sealing ring PTFE, gear PEEK
• lifespan: 5000-8000H
• Drive mode: none
• Viscosity range: 0-3000CP
