Samin Instruments - Model MPDSS -Multi Purpose Digital Survey System
MPDSS is quite a multifunctional survey system that can meet all your needs when it comes to using the device in all areas and directions with the lowest price ever. What makes this device different from other similar systems is the way it works in very vertical boreholes that makes it into an accurate and very fast tool to measure the real azimuth inside the vertical borehole.
MPDSS including high accuracy inclinometer and gyroscope to measure Dip and Azimuth. This device can operate in single shot, multi shot or continuous mode. In continuous mode you can survey borehole quickly ( up to 100 meter per min ) with Wireline and be sure the data is still accurate.
By using MPDSS , it is possible to survey the oriented and vertical borehole in all areas such as mines or grout curtain . This tool reduces the risk of missing the tool inside of the borehole because the tool is used in the drill string. moreover, the required data collected as accurate as you think.
MPDSS has another feature that is the very light weight it has and let you evaluate the smallest boreholes with 36 mm using the least equipment you have. primary orientation inside the borehole could be done accurately and very quickly.
