Oceantek - Model H3-OCEAN-600 -Self-contained Hydrophone

• Operating Frequency: 10Hz – 20kHz
• Continuous Working Time: ≥ 1 month
• Maximum Gain: -18dB to 24dB

• Ultra-Long Autonomous Monitoring
  Self-contained design with built-in high-capacity battery enables continuous underwater recording for over 1 month, and even supports up to 370 days of scheduled interval sampling for unattended deep-sea deployments.
• High-Sensitivity Low-Noise Acoustic Detection
  Optimized for capturing faint underwater sounds, featuring ultra-high sensitivity and low self-noise performance, making it ideal for marine mammal monitoring, seismic studies, and ambient noise research.
• Wide Frequency & Flexible Sampling Options
  Covers a broad frequency range (10 Hz–20 kHz) with multiple adjustable sampling rates, allowing users to tailor data collection to specific research or monitoring needs.
• High-Resolution & Large Dynamic Range Recording
  24-bit quantization paired with a wide dynamic range ensures clear, detailed capture of both faint and loud acoustic events without signal distortion.
• Deep-Sea Ready & Compact Design
  Rated for 6000 m depth, with a rugged, compact form factor that is easy to deploy and retrieve, suitable for moorings, seabed stations, and long-term ocean observatories.
• Large On-Board Storage & Fast Data Access
  Standard 512 GB storage (up to 1 TB optional) supports extended recording missions, with high-speed data download capability for efficient post-mission analysis.
• Low Power Consumption for Extended Field Life
  Ultra-low continuous power draw maximizes deployment duration, making it ideal for remote, long-term ocean monitoring projects.
• High-Reliability for Marine Research & Applications
  Built to withstand harsh deep-sea conditions, delivering stable and consistent acoustic data for marine biology, oceanography, environmental monitoring, and underwater noise studies.

Technical Specification: H3-OCEAN-6000 Self-contained Hydrophone

• Model: H3-OCEAN-6000
• Product Type: Self-contained Hydrophone
• Pressure Rating: 1000m, 3000m, 6000m (Max rating: 6000m)
• Operating Frequency: 10Hz - 20kHz
• Operation Mode: Self-contained
• Continuous Working Time: ≥ 1 month
• Hydrophone Sensitivity: Better than -166dB re 1 µPa (including preamplifier module)
• Sampling Rate: 8kHz, 16kHz, 32kHz, 64kHz, 128kHz (adjustable)
• Interval Sampling: Supports up to 370 days of monitoring
• Sampling Quantization Precision: 24-bit quantization
• Dynamic Range: > 100dB
• Minimum Measured Noise Spectral Level: < 40dB @ 1kHz
• Maximum Gain: -18dB to 24dB
• Power Supply: 7.2V, 480Wh
• Power Consumption: Continuous operating power consumption: better than 500mW
• Data Download Speed: ≥ 5 MB/s
• Internal Storage Capacity: 512GB nominal (optional 1TB)
• Weight (with battery): < 4kg
• Dimensions: Hydrophone volume: Φ40mm (diameter) × 105mm (length)
• Main body volume: Φ74mm (diameter) × 315mm (length)

• Wide Frequency Band
• Long Continuous Operation
• Low Self-Noise
• Captures noise below sea state 0
• Compact Size
• Flexible installation
• High Quantization Accuracy
• Strong Environmental Adaptability
• Atomic Clock Module
• Synchronized multi-unit data acquisition
• Titanium Alloy Pressure Housing
• Deep-sea operation ready

• Marine Biological Research
• Seismic Exploration
• Fish School Location
• Deepwater Oil and Gas
• Renewable Energy
• Leakage Inspection

High Reliability
Continuous operation: ≥100 days

Small Size
Far smaller size than global counterparts with equal performance

Cost-Effective
Stable performance, affordable and reliable

Manufacturer
Faster response & shorter delivery time

One Year Warranty
Extended warranty available. Contact us for details.

After-sales Service
After-sales support via email, telephone,social media such as WhatsAPP
