Kingda - Model TL Series -Single-Casing Desulfurization Pumps
This series of desulfurization circulating pumps features a horizontal, axial suction, single-stage, single-suction, suspended, and rear-extraction structure. The single-layer casing and flow-through components are made of KB09 material, specifically developed by our company for desulfurization operations. This material boasts high efficiency and energy saving, corrosion and wear resistance, low vibration, low noise, reliable operation, leak-free shaft seal, long service life, and convenient maintenance. The pump`s overall performance is among the leading levels in China.
This series of desulfurization circulating pumps features a horizontal, axial suction, single-stage, single-suction, suspended, and rear-extraction structure. It has a single-layer casing, and the flow-through components are made of KB09 material, specially developed by our company for desulfurization operations. This material offers high efficiency and energy saving, corrosion and wear resistance, low vibration, low noise, reliable operation, leak-free shaft seal, long service life, and convenient maintenance.
Suitable for conveying limestone or gypsum slurry in desulfurization systems of industries such as thermal power generation, aluminum smelting, and oil refining. It allows for slurry with a chloride ion content up to 60,000 ppm, a pH value between 4 and 13, a slurry temperature ≤70?, and a slurry weight concentration (Cw) up to 60%.
- Product Model: TL series single-casing desulfurization pumps
- Diameter (mm): 65-1000
- Flow rate (m³ / h): 50-18000
- Head (m): 15-50
- Material: M
