Envea - Model AF22e -Sulfur Dioxide Analyzer (SO2)
UV Fluorescence gas monitor offering excellent performances for the monitoring of SO2 in the range 0-10 ppm or 0-1 ppm. Option: H2S / TRS monitoring. Eco-designed, reference air quality monitor, QAL1 certified by the TÜV, US-EPA approved. Utilizes the standard method for the measurement of sulfur dioxides (EN 14212). With its ultra low power consumption & 24 V supply (option), the AF22e is the sole SO2 monitor on the market able to measure without being connected to the power grid.
- Superior metrological performances for SO2 measurements in ranges 0-10 ppm or 0-1 ppm
- Innovative design of the optical module for excellent sensitivity and signal stability
- Real-time calibration graph, animated synoptic, auto-diagnostic, control and maintenance data screens can be displayed while the instrument is operating
- Embedded Communication Protocol for XR® Software with automatic recognition and configuration
- Able to withstand temperatures up to 45-50 °C without air conditioning
- Special architecture means that no additional pump is necessary in case of permeation bench (in option)
- Automatic recognition of plugged electronic boards or optional devices: plug & play principle
- Smart, connected instrument with embedded web server for the easiest, full remote control and operation of the analyzer from any PC, tablet or smartphone (configuration, calibration, test, diagnostic parameters…)
MAIN OPTIONS:
- Analyzer without screen for reduced environmental impact
- Additional parameters: SO2, H2S, CH2SH, COS, CS2, (CH2)2S…
- 24 V Power supply PLUS extended temperature range 0-50°C
- Built-in permeation bench with SO2 tube (additional pump not required)
- Internal converter for H2S monitoring (range 0-1000 ppb)
- CTRS External module, to be used in combination with the AF22e SO2 analyzer for the continuous measurement of TRS compounds or cyclic measurement SO2/TRS
- Continuous indoor and outdoor air quality monitoring
- Stationary and mobile AQMS laboratories
- Industrial fence-line monitoring
- Continuous emissions monitoring (CEM) by dilution
- Laboratory & field studies on SO2 / H2S / TRS effects…
- Background (urban or suburban) Rural, Traffic, Kerbside measurement campaigns and monitoring studies
- Measured parameter: SO2
- Technology: UV Fluorescense
- US-EPA Approval / QAL 1 Certification: YES
- Measurement ranges: 0-1 ppm or 0-10 ppm user-defined
- Measurement units: ppb, ppm, µg/m3 user-defined
- Lower Detectable Limit (2σ): < 0.4 ppb
- Noise (σ): < 0.2 ppb
- Zero drift: < 1 ppb / 24h
- Span drift: < 0,5% / 7 days
- Linearity: ± 1%
- Sample flow rate: 20L/h
- Sample pump: internal
- Temperature range: 0°C to +35°C
- Data storage: 1 year
- Included I/O: 1LAN/3USB/WIFI/2DRY
- Weight (Kg): 9,8
- Dimensions mm (LxWxH): 483 x 606 x 133
- Case: 19″ Rack, 3U
- Power supply: ‘100~250Vac, 50/60Hz + ground
- Pressure and temperature compensation: YES
- 2008/50/EC, EN 14212, EN 15267, 40 CFR PART 53 SUB B and SUB C
- QAL 1 certified by the TÜV to N° 0000051690
- U.S. EPA approved as compliant with EQSA-0802-149
ENVEA monitoring solutions are European QAL 1 certified and in compliance with the latest international regulations & standards.
They are also approved and certified by various laboratories and organizations around the world such as: US EPA, TÜV, GOST, CEN, JQA, CNEMC, JMOE, KTL, CNSA, LCSQA…
