Gallop - Surface Flow Velocity Radar Meter

Surface velocity radar meter is an ideal solution for non-contact measurement of fluid surface flow rate for river, canal, channel, pipeline.

• Built-in compact enclosure, built-in transmitter and sensor
• Strong IP68 protection
• Plug and play, online real time measurement
• Ultra low power consumption, suitable for outdoor applications
• RS485 digital communication, minimize wiring and engineering costs
• Standard Modbus RTU protocol, directly connected to PLC and HMI
• It is not affected by temperature, rainfall, snowfall, turbidity, suspended solids, steam, steam and sandstorm
• Data monitoring, calibration, configuration and diagnostic software tools

Parameters

• Measuring range : 0.05-15m/s
• Measurement accuracy : ±0.01m/s
• Radar antenna : Planar microstrip pulse coherent radar
• Radar frequency : 24GHz (K-Band)
• Effective distance : ≤ 40m

Interface and Others

• Digital interface : RS232\RS485
• Analog output : 4-20mA
• Working voltage : 7~28VDC
• Shell material : plastic
• Protection level : IP68
• Working Temperature : -35~70?
• Lightning protection : lightning protection level 6KV

• Hydrological surveys such as rivers and flood control
• Rivers, irrigation channels, water resources monitoring
• Environmental pollution discharge, underground water pipeline network monitoring
• Urban flood control and mountain rainstorm monitoring

1. The probe is measured against the direction of water flow and tilted 45 ° C
2. Choose a place with a larger wave to measure more accurately
3. Do not have water plants in the direction of measurement
