Himalaya - Model K - Series -Three Roll Plate Bending/Rolling Machine

Himalaya’s Linear Guided Plate Bending Machines deliver at par performance and flexibility at much lower costs compared to the more expensive 4-roll plate bending machines. They are also extremely durable and accurate compared to swing guide machines and are therefore ideal for medium-to-heavy duty rolling.

The bottom rolls in our linear guideway plate rolling machines, are positively guided in the machine frames. The axis of bottom rolls is closer to the top roll. The close spacing between top roll and bottom rolls improves circularity of the rolled shell. Hence accuracy of resultant job is better than swing guide or variable geometry machines.

Our design ensures that the bending forces are directly transferred from cylinders to rolls, as no linkages are involved in our design. Hence, there is no wear and tear of the guideways and roll parallelism is maintained. Compared to this, the swing-guide design transfers the load to the links on which the rolls are hinged which are weakest part of the joint and can result into increased chances of fatigue and failure.

The front and back frames of our machines are cut and machined together as a single piece. This leads to an extremely accurate alignment of the guideways in which the bottom rolls move. This results in excellent precision of roll movement and superlative bending quality.
