Scotia - Model SUDS / SSDG -Underwater Datalogging System

An overview of both the Scotia Underwater Datalogging System and the Scotia Subsea Digital Gauge.

Most popular related searches

Rated subsea depth of 3000m
Measures and logs up to 5 transmitters
Measures and logs water depth and temperature
Measures and logs up to 3 ow rates or totals
Alarm can be set for any channel
Hand held terminal for easy set up of parameters in the eld
Logging intervals from 2 seconds to 10 hours with 32Mb non-volatile memory.
Logging can be continuous for 10 days or up to a year at an interval of 15 minutes using sleep mode or delayed start to conserve battery life
ROV friendly with light sensitive backlit display and easily operated On/o switch
Rechargeable battery with onboard condition monitor
Download automatically to SDAS software using USB memory stick attached to any PC or laptop
Secure SDAS data les can be printed in graphical or tabular form or exported in ASCII text format for import into non-secure documents and spreadsheets

Surface Communications utilising “DATUM” Digital Acoustic Transponder & Underwater Modem
Subsea Omni-Directional transponder allowing the transmission of live data for shipboard retrieval via the Scotia Transponder
SUDS can reacquire transponder and download data whilst still logging allowing ship manoevering whilst testing
Fitted with two onboard batteries when congured with transponder
At 3000m depth, signal range 3-10km approx
Modular Pannier panel with ROV-friendly double valve functionality and integrated pressure sensor
Seatooth (WFS) technology for subsea wireless communication and data download
Logged data can be wirelessly retrieved by an ROV or AUV
Data can be viewed in real-time via ROV umbilical
