MERATCH - Water Level Sensor
A solution combining an innovative IoT sensor and software which can be adapted to the individual needs of each client moves water monitoring to the 21st century. It can also measure temperature and other water parameters wirelessly. With easy installation and connectivity to every IoT network and even satellite, MERATCH can be helpful anywhere in the world.
Most popular related searches
water level sensor
thermal cycle
IoT sensor
optical inspection
data logger
level sensor
water monitoring
water sensor
resistivity data
ultrasonic monitor
- FOTA : over-the-air firmware update.
- Onboard data logger : memory unit for ex-post sensor diagnostics.
- Certification validation : approved by Deutsche Telekom AG & Vodafone.
- Own antenna design : optimized for all global IoT networks (Sigfox, LoRa, NB-IoT).
- Private APN : secured connection between the sensor and the cloud by private APN.
- Data consistency : resistance to connectivity outage. Data is not lost but is being transmitted after connectivity recovery.
- Embedded coulombmeter : reliable online and onboard battery consumption and health monitoring.
- Ultrasonically welded : casing for 100% hermetic sealing with IP68 ingress protection.
- Minimalistic form factor : straightforward installation and also de-installation thanks to adapter.
- AOI and RTG inspection : Electronic assembly inspected by AOI (automatic optical inspection), and RTG.
- Tested and inspected : for an operational lifetime using thermal cycling chamber (-30 to +60 °C), simulated age of 6 years.
- Side mounting : Using flat head countersunk screws
- Magnetic top mounting : Using flat head countersunk screws with magnetic washers
- Top mounting : Using longer screws, reaching through our mounting adapter into mounting object
- Mounting to pole : Using steel mounting strap
Dimensions
Size: diamater:90 mmheight:52 mm
Weight:300g
Casing: Ultrasonic welded plastic into one piece
Measuring
Method: nanoradar
Resolution: 0.5 mm
Distance: 0.03 m - 22.7 m
Environment
Protection: IP68, IK10
Operation temperature: -40°C to +75°C
Battery & Power
Battery life: ~ 8 years
Power: 3.6V, 14 Ah alt. 19 Ah
Connectivity
Networks : LoRa, Sigfox, NB-IoT, Satellite
