Calibration Services
UKAS Traceable Calibration and repair services. Over the course of a flow meters lifetime it is recommended to be calibrated at regular intervals to maintain best accuracy. Without re-calibration, the accuracy of the meter can drift resulting in poor repeatability measurements and general under-performance which could affect your process and product quality.
The iCenta UKAS Traceable calibration service helps you maintain your standards cover flow ranges from 0.015-5000 l/min.
On receipt of your flow meter, we evaluate the condition (inspecting the equipment for visible signs of damage to rotor sensors, electrodes and electronics), measure the flow rate of the instrument, compile a report and provide a quotation to calibrate and if necessary adjust and repair the instrument. The instrument is returned with a calibration / test report with your choice of measurement points normally 3-10 with several repeats.
Our small volume prover (SVP 250) is capable of measuring a variety of liquid viscosities from 0.6 – 100 m²/s (Cst) with flow ranges from 12 ml/min to 1000 l/min with a typical 0.04% accuracy. The SVP can measure several fluids (but not limited to):
- Water
- Diesel /Kerosene
- Synthetic and non-synthetic oils
- Alcohol
- Hydrocarbons
- Biofuels
- Methanol
Some of the many types of flow technology we calibrate, and service are as follows;
Electromagnetic (Mag), Turbine, Oval Gear, Positive Displacement, Coriolis Mass, Vortex , Ultrasonic, Thermal, Paddlewheel (Pelton Wheel), Variable Area (Rotameter)
UKAS traceable liquid calibration range we offer is:
Piston Prover: 10 ml/min – 1000 l/m (liquids: water, oils and hydrocarbons to 100 centistokes ± 0.08% RD (Est.) Max Temperature 80 Deg C
Gravametric: 0.5 – 30 l/m (liquids: water ± 0.15% RD)
Volumetric: 13.5 m³/hr – 300 m³/hr (liquids: water)
We calibrate to the following measurement points as standard, other points may be available on request):
- 5 points
- 8 points
- 10 points
- Custom Point
Calibration at customer specific temperatures and viscosities
All calibrations will take approximately 5 – 7 days to complete from receipt of the flow meter. A special 24-hour service may be available for some products, please enquire.
