Sample Analysis + Pilot Testing Services
A first step, small-scale sample analysis gives our customers better insight into their process feasibility, optimization, equipment scaling and how to maximize efficiencies. Sludge samples are tested and analyzed, the data is reviewed - with recommendations for next steps by our Process Engineers and R&D Teams.
- Solids Analysis (total - dissolved - suspended or volatile solids)
- Polymer Screening
- Coagulant Screening
- Clarification Analysis
- Dewaterability Analysis
- Particle-size Analysis
- Nutrient Analysis
- Biological Methane Testing - partnership with Marquette University
A full-scale pilot test is proof-of-concept used to demonstrate the viability of equipment and/or a process on-site at your plant. Using the data collected from your plant`s sludge or slurry gives us more precise information which is needed to make the most accurate recommendations to meet or exceed your plants performance goals.
A pilot test helps to better determine: equipment sizing, throughput, solids capture, cake solids and polymer selection. A written report is provided to summarize the results.
Centrisys/CNP provides full-scale pilot testing equipment and services for the following:
DEWATERING
- CS Series 2-phase centrifuge trailer (dry and emulsion polymer preparation, polymer aging system and testing lab) (70-250 gpm)
- CS Series 2-phase centrifuge skid system (30-500 gpm)
- CS Series 2-phase centrifuge (1-5 gpm)
- CS Series 3-phase centrifuge skid system (5-10 gpm)
- SP Series screw press (3-20 gpm)
THICKENING
- THK Series sludge thickener (5-250 gpm)
RESOURCE RECOVERY
ANCILLARY EQUIPMENT
- Pick Steam injection system
- Vogelsang grinder
- Polymer dosing system
- Coagulant dosing system
- Stainless steel reaction tank
- Transfer pumps
BENCH TOP STUDIES
- Swing-Out Bench Top Centrifuge (10-500 ml)
- Gang Mixer
- Settling Column
- Brookfield-Style Viscosity Meter
