Tool Design Service
Industrial Rubber’s Technical Team along with our well established Partners are able to Design and Manufacture Tooling and other equipment required for the manufacture of the vast range of Rubber Components from less than 1 gram up to 40 Kilos.
We can Manufacture Tooling from Single Cavities for Prototypes or Low Volume Production through to fully hardened Multi-Cavity Tools for High Volume Production. We manufacture tools for:
- Compression Moulding
- Transfer Moulding
- Injection Moulding both Thermoset Rubber and TPE
- Corner Moulding and Jointing of Extrusions
- Sponge Rubber
Industrial Rubber are able to work from samples (see Reverse Engineering section) 2D Drawings of full 3D CAD Data of the required component to design, and manufacture tooling best suited to the application be it large or small volumes.
Industrial Rubber can accept CAD Data in a variety of formats including:
- DXF, DWG, STP, IGS, x_t
Our toolmakers are equipped with the latest CAD/CAM software. They have CNC and 5 AXIS machine tools and all the necessary ancillary equipment you would expect to find in a modern tool room. They also have CMM (coordinate measuring machines) for the inspection of the finished tools.
