O2 SL – Plastic Oxygen Sensor

Typical applications include the measurement of Oxygen deficiency in confined spaces such as tunnels, mines or chemical plant or for the analysis of combustion gases in flues and chimney stacks.

The SL`s shock resistant, leak free design ensures lifetime reliability. High sensor to sensor repeatability and high tolerance to temperature and pressure transients also contribute to highly reliable performance. All SL oxygen sensors have lifetimes of 18 months.

Operating Principle: 2-electrode cell
Gas Detected: Oxygen
Measurement Range: 0 - 25% v/v
Maximum Overload: 30% v/v
Expected Operating Life: 18 months in air
Output Signal: 0.42 + 0.06mA in air
Temperature Range: -20°C to +50°C
Pressure Range: 1atm + 10%
Humidity Range (non-condensing): Continuous: 15-90% RH
Intermittent: 0-99% RH
Response Time (T5 90): <10 seconds
Pressure Co-Efficient: <+0.003% of signal per mBar
Temperature Co-Efficient <+0.2% of signal per°C
Long Term Output Drift: <+2% of signal per month
Repeatability: <+1% of signal
Linearity: Non-Linear 1.7818#(ln(1/(1-(%02/100)
Recommended Load Resistor: 47Q
Bias Voltage: Not required

Maximum at 100% v/v Oxygen: 6.4mA
Maximum o/c Voltage: 0.9V
Maximum s/c Current: 500mA

Weight: 32g
Orientation: Any
Storage Life:
6 months in sealed container
Storage Conditions:
10-20 °C, 45-75% RH in clean air
Warranty Period:
12 months from date of despatch
Part Number: 2112B4530
