12d Model - Sewer Module

The Sewer module is an extension of the Drainage module and supports the design of gravity operated waste water reticulation systems, typically those required for new land subdivisions (estates) and development projects. When satisfied with the design invert levels, connections from the design line to the individual house blocks can be added and reported on. The special waste water reticulation longitudinal plots show existing surface, manholes, design pipelines, pipe grades, property connection points and all obstructions.
